5.6 Mounting the DIL s witch cover
1. Place cover on the bus node. Make sure that the seal is positioned correctly!
2. Tighten the two mounting screws with a max. torque of 0.4 Nm.
6 Connecting to the networ k
Use shielded Industrial Et hernet cables of category Cat 5 or higher.
6.1 Cable specification
Feature
Requirement
Cable type Ethernet twisted pair cable, screened
Transmission class Category Cat 5 or higher
Core cross section 0.14 ... 0.75 mm
2
22 AWG required for max. connection length between
network par ticipants
Connection length Max. 100 m
Fig. 10
7 Power supply of the CPX terminal
The operating and load voltage supply for the CPX terminal runs over interlinking
blocks. The interlinking blocks carry the operating and load voltage over contact
rails to the adjacent modules ( CPX system description P.BE-CPX-SYS…).
8 Start-up behaviour of the CPX terminal
If the LED “M” illuminates or flashes permanently after the system start, “System
start with saved parameterisation and saved CPX expansion” is set or “Force” is
active.
9 Note on module replacement
Note
Loss of settings
If the LED “M” of the bus node is permanently lit, parameterisation of the CPX
terminal is saved locally in the bus node. In this case, parameterisation is lost if
the bus node is replaced.
• Before replacement, secure required settings and make them again after
replacement.
10 Parameterisation
The CPX terminal and the related bus node c an be parameterised by means of the
Festo operator unit (CPX-MMI), Festo Maintenance Tool (CPX-FMT) or EtherCAT
(CoE). The CPX modules are made available in the configuration file (ESI file).
You can find the current configuration files (ESI files) and additional in-
formation on the Festo Internet page in the Support Portal
(
www.festo.com
/sp).
Further information on parameterisation and module replacement can be
found in the bus node description P.BE-CPX-FB37-...
(
www.festo.com
/sp).
11 Technical data
Feature
Specification/value
General techn ical data CPX system description P.BE-CPX-SYS-...
Degree of protection through housing
in accordance with IEC/EN 60529,
completely mounted, plug connector
inserted o r provided with cover cap
IP65/IP67
Protection against electric shock
Protection against direct and indirect
contact in accordance with IEC/EN 60204-1
by means of PE LV po wer circuit
Bus node intrinsic current consumption
from operating voltage supply for
electronics/sensors (U
EL/SEN
)
typically 100 mA at 24 V (internal electronics)
Separation
EtherCAT interfaces for U
EL/SEN
galvanically separated
Module code (CPX-specific)
Remote I/O 224/2
Remote controller 171/2
Network-specific characte ristics
Protocol EtherCAT, based on the Ethernet protocol IEEE
802.3, optimised for process data, real-time
capable
Transmission rate 100 Mbit/s
Crossover detection Auto-MDIX
Fig. 11
