Festo — CPX(-M)-FB33/34/35/43/44/45 — 2022-05f
Diagnostics
Description Replacement marker Data type
Brief description of the CPX module
name
<CPX:Mx_SHORTTEXT> String
Input offset of the CPX module in the
input process data container
<CPX:Mx_INOFFSET> Number
Occupied input bytes of the CPX
module in the input process data con-
tainer
<CPX:Mx_INBYTES> Number
Output offset of the CPX module in the
output process data container
<CPX:Mx_OUTOFFSET> Number
Occupied output bytes of the CPX
module in the output process data
container
<CPX:Mx_OUTBYTES> Number
Software revision of the CPX module <CPX:Mx_SWVER> String
Hardware revision of the CPX module <CPX:Mx_HWVER> String
Number of parameters of the CPX
module
<CPX:Mx_PARAMCOUNT> Number
Name of the parameter of the CPX
module
<CPX:Mx:Px_NAME> String
Value of the parameter of the CPX
module
<CPX:Mx:Px_VALUE> String
Profinet error number <CPX:Dx_DIAG_MESSAGE_ID_PRO-
FINET>
Number
Source of error ("MODULE",
"CHANNEL")
<CPX:Dx_DIAG_MESSAGE_SOURCE> String
Error degree of severity ("Info",
"Warning", "Error")
<CPX:Dx_DIAG_MESSAGE_TYPE> String
Error status ("Raised", "Resolved") <CPX:Dx_DIAG_MESSAGE_STATUS> String
CPX error number <CPX:Dx_DIAG_MESSAGE_ID_CPX> Number
Error text <CPX:Dx_DIAG_MESSAGE_TEXT> String
Tab. 25: Replacement markers
9.8.2
Telegrams with template selection 0
9.8.2.1 Online
Is sent when the connection to Broker has been established.
Topic
<TOPIC_PREFIX>/ONLINE/<TEMPLATE_VERSION>/<TEMPLATE_SELECTION>
