Festo — CPX(-M)-FB33/34/35/43/44/45 — 2022-05f
Product overview
Function Bus bus node revision number
Software Hardware
PROFIenergy from Rev 20 from Rev 1
Media Redundancy Protocol
(MRP)
from Rev 20 from Rev 1
Media Redundancy for Planned
Duplication (MRPD)
from Rev 50 from Rev 45
S2 system redundancy from Rev 50 from Rev 45
Isochronous real time (IRT) from Rev 21 from Rev 1
Message Queuing Telemetry
Transport (MQTT)
from Rev 53 from Rev 45
Tab. 3: Required revision numbers for using the functions
The bus nodes CPX(-M)-FB33/34/35 do not support MQTT.
The revision numbers of the hardware and software for the bus node can be checked with the control
software, the Festo Maintenance Tool (FMT) or the Festo Field Device Tool (FFT).
4.2.3
LED displays
LED Network status LEDs LED CPX-specific LEDs
NF Network Failure, red PS Power System, green
M/P Maintenance/PROFIenergy,
green or yellow
PL Power Load, green
TP1 Link/Traffic 1, green SF System Failure, red
TP2 Link/Traffic 2, green M Modify, yellow
Tab. 4: LEDs on the bus node
