Diagnostics
Payload
{
"DIAG":{
"Timestamp":"<CPX:FBD_TIMESTAMP>",
"TimestampQuality":"<CPX:FBD_TIMESTAMP_QUALITY>",
"TemplateSelection":<TEMPLATE_SELECTION>,
"TemplateVersion":"<TEMPLATE_VERSION>",
"ModuleNumber":<CPX:Mx_MODULE_NUMBER>,
"MessageSource":"<CPX:Dx_DIAG_MESSAGE_SOURCE>",
"ChannelNumber":<CPX:Mx:Cx_CHANNEL_NUMBER>,
"ChannelType":"<CPX:Mx:Cx_CHANNEL_TYPE>",
"PNDeviceName":"<PN:PDN>",
"PNErrorCode":<CPX:Dx_DIAG_MESSAGE_ID_PROFINET>,
"MessageType":"<CPX:Dx_DIAG_MESSAGE_TYPE>",
"MessageStatus":"<CPX:Dx_DIAG_MESSAGE_STATUS>",
"MessageId":<CPX:Dx_DIAG_MESSAGE_ID_CPX>,
"MessageText":{
"en-US": "<CPX:Dx_DIAG_MESSAGE_TEXT>"
}
}
}
The entries for ChannelNumber and ChannelType are omitted in the case of module diagnostics.
9.8.2.7 Want
The telegram is sent by Broker if the connection between the bus node and Broker has been inter-
rupted.
Topic
<TOPIC_PREFIX>/LASTWILL/<TEMPLATE_VERSION>/<TEMPLATE_SELECTION>
Payload
{
"LASTWILL":{
"TemplateSelection":<TEMPLATE_SELECTION>,
"TemplateVersion":"<TEMPLATE_VERSION>",
"Publisher":"Offline"
}
}
