36
Festo — CPX(-M)-FB33/34/35/43/44/45 — 2022-05f
Technical data
Characteristics CPX-FB43 CPX-M-FB44 CPX-M-FB45
Module code in the CPX Ter-
minal
–
Remote I/O
–
Remote Controller
–
Sub-module code
215
164
32
216
165
32
217
166
32
Module identification
–
Remote I/O FB43-RIO PROFINET
remote I/O
FB44-RIO PROFINET
RJ45 remote I/O
FB45-RIO PROFINET
LWL remote I/O
–
Remote Controller FB43-RC PROFINET
I/O bus node
FB44-RC PROFINET
RJ45 bus node
FB45-RC PROFINET
LWL bus node
Power supply
Operating voltage/load voltage è CPX system description (CPX-SYS-…)
Internal current consumption of
the internal electronics at a
nominal operating voltage of 24
V DC,
from operating voltage supply
for electronics/sensors, U
EL/SEN
Typ. 75 mA Typ. 75 mA Typ. 150 mA
Separation of the PROFINET
interfaces to U
EL/SEN
Electrically isolated
by transformer up to
1500 V
Electrically isolated
by transformer up to
1500 V
Electrically isolated
by fibre-optic cable
Mains buffering time 10 ms 10 ms 10 ms
Accuracy in voltage measure-
ment of the operating or load
voltage
£ 5% £ 5% £ 5%
Tab. 28: Special characteristics of CPX-(M)-FB43/44/45
