Festo LF-D Series User Manual

Product specific specifications
Key:
Size of connection
Module no.
Service unit type Part no.
Normal rated flow
Type -MINI-... -MIDI-... -MAXI-...
-1/8- -1/4- -3/8- -3/8- -1/2- -3/4- -3/4- -1-
122 995 120 515 123 592
LF-...-D-... 159 612 159 613 162 606 159 576 159 578 162 607 159 614 159 615
122 996 120 516 123 593
LF-...-D-...-A 159 616 159 617 162 608 159 577 159 579 162 609 159 618 159 619
a 800 l/min 1000 l/min 1100 l/min 2500 l/min 2600 l/min 2700 l/min 5000 l/min 5300 l/min
127 300 127 308 127 315
LF-...-D-5M-... 162 610 162 611 162 612 162 613 162 614 162 615 162 616 162 617
127 302 127 309 127 316
LF-...-D-5M-...-A 162 618 162 619 162 620 162 621 162 622 162 623 162 624 162 625
a 600 l/min 700 l/min 800 l/min 1700 l/min 1800 l/min 1900 l/min 3000 l/min 3200 l/min
123 587 120 518 124 085
LFR-...-D-... 159 630 159 631 162 682 159 582 159 584 162 683 159 632 159 633
123 589 120 519 124 086
LFR-...-D-...-A 159 634 159 635 162 684 159 583 159 585 162 685 159 636 159 637
b 750 l/min 1400 l/min 1600 l/min 3100 l/min 3150 l/min 3200 l/min 9000 l/min 10000 l/min
a) Normal rated flow at p
1
= 6 bar, ∆p = 1 bar
b) Normal rated flow at p
1
= 10 bar, p
2
= 6 bar, ∆p = 1 bar
Fig. 31
9607C D/GB 21
