SDAT-MHS
24 Festo – SDAT-MHS – 2017-11f English
10 Technical data
10.1 General
SDAT-MHS-... 50 80 100 125 160
Approval certificate RCM, c UL us - Listed (OL)
CE marking (è Declaration of conformity) In accordance with EU EMC Directive
Note on materials RoHS-compliant
Input signal/measuring element
Sensing range
1)
[mm] 50 80 100 125 160
Signal processing
Typical sampling interval [ms] 1
Max. speed of travel [m/s] 3
Output, general
Displacement resolution [mm] 0.05
Switching output
Switching output PNP
Repetition accuracy of switching point [mm] 0.1
Hysteresis [mm] ≤ 0.3
Analogue output
Analogue output [mA] 4…20
Sensitivity [mA/mm] 0.32 0.20 0.16 0.128 0.10
Typical linearity error [mm] ± 0.25
Repetition accuracy [mm] 0.1
Max. load resistance of current output [Ω] 500
Electronics
Operating voltage DC [V] 15…30
Typical signal running time [ms] < 2
Electromechanical
Cable length [m] 0.3
Conductor nominal cross section [mm
2
] 0.1
Mechanical system
Max. tightening torque [Nm] 0.5
Housing material information PA reinforced, polyester, high-alloy
stainless steel, nickel-plated brass
Immission/emission
Ambient temperature [°C] –25…+70
Ambient temperature flexible cable installation [°C] –20…+70
Degree of protection (as per EN 60529) IP65/IP68
(condition IP68: Test duration 24 h)
1) Type-dependent
Tab. 9 Technical data SDAT-MHS
