SDAT-MHS
30 Festo – SDAT-MHS – 2017-11f English
10.3 I-Port
Note
In principle, the data of the IO-Link specification apply (èchap.10.2).
For specifications on the process data contents èTab. 11.
Index Name Default value Access
1)
Length
0x0040 Device attributes 0x00 R/W 1 byte
0x0041 Extended parameters 0x0000 R/W 2 bytes
0x0042 Diagnosis parameter 0x0000 R 2 bytes
0x0043 Device specific parameters èTab. 20 R/W 8 bytes
0x00FE I-Port Revision 0x0101 R/W 2 bytes
1) Access R = read, R/W = read and write
Tab. 19 Additionally supported parameters in accordance with I-Port specification
Byte 1 2 3 4 5 6 7 8
IO-Link Index 0x003C 0x003D
Subindex 1 2 1 2 3
Function
1)
SP1 SP2 Logic Mode HY
Byte high low high low high low
Default value 0x00 0xAF 0x00 0xFA 0x00 0x00 0x00 0x05
1) Parameter coding èTab. 17
Tab. 20 Device Specific Parameters
