Festo P.BE−K−SFC−DC−... 0801c English24
Warning
Use only power units which guarantee reliable electrical
isolation of the operating voltage in accordance with
IEC/DIN EN 60204−1. Observe also the general
require
ments for PELV power circuits in accordance with IEC/
DIN EN 60204−1.
S Use a regulated power supply.
S Seal unused connections with the protective caps
supplied.
S To gu
arantee correct functioning and protection class:
Line
Accessories type Length [m]
Voltage supply KPWR−MC−1−SUB−15HC−... 2,5 / 5 / 10
Motor KMTR−DC−SUB−15−M12−... 2,5 / 5 / 10
Reference switch e.g. SMT−10 / KM8−M8−...
Serial interface KDI−MC−M8−SUB−9−... 2,5
Control (SFC−DC−...−IO) KES−MC−1−SUB−15−... 2,5 / 5 / 10
Field bus plug/−adapter Accessories type Prot.class
for SFC−DC−...−PB FBS−SUB−9−GS−DP−B
FBA−2−M12−5POL−RK
FBS−SUB−9−WS−PB−K
IP54
IP54
IP20
for SFC−DC−...−CO
FBS−SUB−9−BU−2x5POL−B8
FBA−2−M12−5POL
IP54
IP54
for SFC−DC−...−DN
FBA−1−SL−5POL
FBS−SUB−9−WS−CO−K
IP20
IP20
