Festo SPCAIF−... 0506b Espol
24
2 Elementos de indicación y conexión
12345
76
1
2
1 Conexión de tierra
2 Conexión del sistema
de medicn
3 Conexión para SPC200 (IN)
4 POWERLED (verde)
5 Conexión (OUT) para otros
dispositivos de campo o
resistencia terminadora
tipo KABS−M9R100
6 ERROR LED (rojo)
7 Conexión para la válvula
tipo MPYE5...010B
