Festo SPC−AIF−... 0506b Svenska54
2 Anslutnings− och indikeringselement
12345
76
1
2
1 Jordanslutning
2 Mätsystemsanslutning
3 Anslutning för SPC200 (IN)
4 POWER−LED (grön)
5 Anslutning för ytterligare
fältdon (OUT) eller
termineringsmotstånd
KABS−M9−R100
6 ERROR−LED (röd)
7 Ventilanslutning
MPYE−5−...−010−B
