11 Safety setting
Wire break
Voltage type Current type
Setpoint Output pressure drops to 0 bar. The last value is saved. The output
pressure is maintained but witho ut
closed-loop control. In the medium
term the pressure at the output can in-
crease or diminish.
Supply vo lt-
age
The last value is saved. The output pressure is maintained but not regulated. In
the medium term the pressure at the output can increase or diminish.
Fig. 32
12 Eliminating malfunctions
Cause
Error display
– Value fallen below limit value (setpoint value)
– Value exceeded limit value (setpoint value)
ER.09
ER.10
– Underv o ltage in th e 24V operating voltage
– Overvoltage in the 24V operating voltage
– Hardware error
– Temperature range exceeded in VPPM-...C1
ER.05
ER.26
ER.01
ER.28
Fig. 33
Malfunction
Possible cause Remedy
VPPM-..C1 not re-
acting
Supply vo ltage not applied, POWER LED
does not light up
• Check the 24V DC supply
voltage
Set value vo ltage or set value current not
applied
• Check controller
• Check connection
VPPM-... C1 defective • Send the dev ice to Festo for
repairs.
Flow too low Restriction of the flow cross section due to
connection design (swivel fittings)
• Use an alternative connec-
tion
Pressure increase
too slow
Large cylinder volume and long tubing • Select different parameter
record
• Use larger size VPPM-...C1
Pressure constant
despite modified
setpoint value
specification
– Supply cable breakage (the last output
pressure set is maintained but not regu-
lated. In the medium term th e pressure
at th e o utput can increase or diminish).
– Supply pressure P1 too low
• Replace supply cable
• Increase supply pressure
UP/DOWN but-
tons on th e
VPPM-...C1 do not
react.
Voltage is present at digital inputs D1 and
D2
• Apply 0V DC to digital in-
puts D1 and D2.
Fig. 34
13 Technical data
Note
Certain variants of the product have been cer tified by Underwriters Laboratories
Inc. (UL) for the USA and Canada. Observe the following if th e UL requirements
are to be complied with in your application:
• Rules for observing the UL certification can be found in the separate UL-spe-
cific documentation. The relevant technical specifications listed there also
apply here.
• The technical data in this documentation may show values deviating from this.
General data
Design
Proportional pressure regulator
Mounting position Any, preferably horizo ntal
(display components facing upwards)
Medium Compressed air to ISO 8573-1:2010 [7:4:4],
inert gases
Operation with lubricated medium not pos-
sible
Protection class IP 65 when mounted, with tightened mount-
ing screws, in connection with plug socket
according to “Accessories”.
Permissible temp. r ange
– Ambient temperature
–Medium
–Storage
[°C]
0 ... +50
+10 ... +50
–10 ... +70
General data
Vibration and shock
–Vibration
– Shock
The following data does not apply to mount-
ing the VPPM... to the angle bracket VAME-
P1-A.
tested according to DIN/IEC 68/EN 60068
part 2-6;
With wall mounting:
0.35mm path at 10 ... 60Hz
5 g acceleration at 60 ... 150Hz
Checked as per DIN/IEC 68/EN 60068 Part
2-27
With wall mounting:
±30 g at 11 ms duration; 5 shocks per direc-
tion
Materials
Housing
Cover
Seals
Lubrication
Wrought aluminium alloy
P AXMD6-GF50/gr-P, PA6-GB20,GF10/gr-P
Nitrile rubber
Silicone-free
Weight [g] 1/8”: 400
1/4”: 560
1/2”: 2050
Fig. 35
Pneumatics data
2bartype
30 psi
6bartype
90 psi
10 bar
type
150 psi
Pressure ranges
– Permitted input pressure
– Regulation range
[bar]
0 ... 4
0.02 ... 2
0 ... 8
0.06 ... 6
0 ... 11
0.1 ... 10
Supply pressure p1 at least 1 bar o ve r output
pressure p2
Total leakage when new [l/h] <5
Connections G1/8” (1/8 N PT), G1/4” (1/4 NPT),
G1/2” (1/2” NPT)
Nominal size
– Pressurisation
–Exhaust
[mm]
With 1/8”: 6
With 1/4”: 8
With 1/2”: 12
With 1/8”: 4.5
With 1/4”: 7
With 1/2”: 12
Fig. 36
Data for the electrical components
2bartype
30 psi
6bartype
90 psi
10 bar
type
150 psi
Electrical connection Pin contact M12x1, 8-pin
Perm. operating voltage [V DC] 21.6 ... 26.4 V DC (perm. residual ripple
max. 10 %)
Max. electrical power consumption
– Nominal size 1/8” and 1/4”
– Nominal size 1/2”
[W]
7
12
Power rating of digital switching out-
put D3 (PIN 8 in el. connection)
[mA]
Max. 60
Max. perm. supply and signal line
length
[m]
10
Over all accuracy
– Standard (2 %) +0.5 x hysteresis
– Class S1 (1 %) +0.5 x hysteresis
[bar]
0.045
0.025
0.135
0.075
0.225
0.125
Hysteresis 0.5 % Full scale
Voltage type VPPM-...-V1.-...C1
– Setpoint value size
– Input resistance (setpoint value)
– Working resistance of actual value
output
Current type VPPM-...-O4.-...C1
– Setpoint value size [mA]
– Input resistance (setpoint value)
– Working resistance of actual value
output
[V DC]
[kΩ]
[kΩ]
[mA]
[Ω]
[Ω]
0 ... +10
10
Min. 2
4 ... 20
250
max. 500
Electromagnetic compatibility (EMC)
*)
– interference emission and resist-
ance
See declaration of conformity
 www.festo.com
CE conformity for industrial installations ful-
filled.
1) The valve is intended for use in an industrial environment. Outside of industrial environments, e.g. in
commercial and mixed-residential areas, actions to suppress interference may have to be taken.
Fig. 37
