10
Angle attachment [5]
Drilling and screwdriving at right angle to machine
(partly as an accessory).
Tool holder in the drill spindle [6]
Bits can be inserted directly into the hexagon sock-
et holder of the drill spindle.
Depth stop [7]
The depth stop (partly as an accessory) allows the
user to insert screws to a predefined depth. You can
set the dimension by which the screw head pro-
trudes above or is recessed below the surface of the
workpiece.
Depth setting
Turn the housing
[7-1]
to set the
desired fastening depth. Each
detent position changes the fastening depth by 0.1
mm.
Sleeve A/B must be removed before a screw can be
unscrewed.
5
1
2
click
6
7
