Festool PDC 18/4 Instruction Manual

7
Technical data
* Speed specifications with fully charged battery pack.
** The maximum speed is reduced in the lower torque stages (values in counterclockwise rotation).
Functional description
The pictures for the functional description are on a
fold-out page at the beginning of the instruction
manual. While reading the manual you can fold out
the page for comparison and quick reference.
Cordless percussion drill PDC 18/4
Motor voltage 18 V
Idling speed* 1st gear 0 - 400 min
-1
2nd gear 0 - 850 min
-1
3rd gear 0 - 1850 min
-1
4th gear 0 - 3800 min
-1
Torque for easy/tough fastening applications 40/60 Nm
Adjustable torque** 1st gear 1.2 - 11.5 Nm
2nd gear 0.8 - 7.2 Nm
3rd gear 0.6 - 4.7 Nm
4th gear 0.6 - 2.6 Nm
Chuck clamping range 1/16" - 1/2" (1.5 - 13 mm)
Drill diameter max. Wood 1 31/32" (50 mm)
Metal 1/2" (13 mm)
Fastening in pine max.  3/8" (10 mm)
Tool holder in drill spindle 1/4"
Weight without battery pack with Centrotec 2.9 lbs (1.3 kg)
[1-1] LED light switch
[1-2] LED lamp
[1-3] Bit store
[1-4] On/Off switch
[1-5] Clamping sleeve
[1-6] Drilling/impact drilling selector switch
[1-7] Gear switch
[1-8] Torque thumbwheel
[1-9] Right/left switch
[1-10] Belt clip
[1-11] Button for releasing the battery pack
