Fetco CBS-2161XTS - Page 3

Go to fetco.com for the latest version of all information 3 P141 REV:002 revised 1/2016 ©December 2015
All brewers HARDWIRE to an internal TERMINAL BLOCK See wiring diagrams for connections
North America CBS-2161XTS—Single 3 gallon version Electrical Configurations
Configuration
Code
Heater
Configuration
Voltage Phase Wires KW Amp Draw
Gallon/[liter]Hour
(3 gallon per batch)
E216151 3 X 3.0 kW 200-240 3 3L+G 6.4-9.1 18.6-22.5 16.4-23.4 [62-88]
(*Optional) 2 X 3.0 kW 200-240 1 2L+G 4.6-6.1 21.2-25.8 11.8-15.7 [44-59]
E216152 3 X 4.0 kW 200-240 3 3L+G 8.4-12.1 24.7-28.9 21.6-30 [82-113]
(*Optional) 2 X 4.0 kW 200-240 1 2L+G 6.1-8.1 28.1-33.8 15.6-20.8 [59-79]
E216153 3 X 5.0 kW 200-240 3 3L+G 10.5-15.1 30.7-36.1 27-30 [102-113]
(*Optional) 2 X 5.0 kW 200-240 1 2L+G 7.6-10.1 35.1-42.2 19.6-26 [74-98]
*Sold as three phase, highest power version
E
q
ui
p
ment ma
y
be field confi
g
urable to sin
g
le
p
hase, lowe
r
-
p
ower, sin
g
le-
p
hase confi
g
uration usin
g
two heaters.
North America CBS-2162XTS—Twin 3 gallon version Electrical Configurations
Configuration
Code
Heater
Configuration
Voltage Phase Wires KW Amp Draw
Gallon/[liter]Hour
(3 gallon per batch)
E216251 3 X 3.0 kW 200-240 3 3L+G 6.4-9.1 18.6-22.5 16.4-23.4 [62-88]
E216252 6 X 3.0 kW 200-240 3 3L+G 12.6-18.1 36.4-43.7 32.4-46.5[123-176]
E216253 3 X 4.0 kW 200-240 3 3L+G 8.4-12.1 24.7-28.9 21.6-28.9 [82-113]
E216254 6 X 4.0 kW 200-240 3 3L+G 16.8-24.1 48.4-58.1 43.1-60 [163- 227]
E216272 6 X 3.0 kW 440-480 3 3L+G 13.6-18.1 19.4-22.2 33.2-44 [126-167]
E216271 6 X 4.0 kW 440-480 3 3L+G 20.3-24.1 26.6-29.4 52.2- 60 [197- 227]
International, North America and Japan CBS-2161XTS—Single 3 gallon version Electrical Configurations
Configuration
Code
Heater
Configuration
Voltage Phase Wires KW Amp Draw
Gallon/[liter]Hour
(3 gallon per batch)
E216151* 3 X 3.0 kW 200-240 3 3L+G 6.4-9.1 18.6-22.5 16.4-23.4 [62-88]
E216152* 3 X 4.0 kW 200-240 3 3L+G 8.4-12.1 24.7-28.9 21.6-28.9 [82-113]
E216153* 3 X 5.0 kW 200-240 3 3L+G 10.5-15.1 30.7-36.1 27-30 [102-113]
*Sold as three phase, highest power version
Equipment may be field configurable to single phase, lower-power, single-phase configuration using two heaters as in domestic version
International CBS-2161XTS—Single 3 gallon version Electrical Configurations
Configuration
Code
Heater
Configuration
Voltage Phase Wires KW Amp Draw
Gallon/[liter]Hour
(3 gallon per batch)
E216191 3 X 3.0 kW 220-240/380-415 3 3L,N+G 7.6-9.1 11.7-12.7 19.6-23.4 [74-88]
E216192 3 X 4.0 kW 220-240/380-415 3 3L,N+G 10.2-12.1 15.5-16.9 26.2-28.9 [99-113]
E216193 3 X 5.0 kW 220-240/380-415 3 3L,N+G 12.7-15.1 19.3-21.0 32.6-37.8 [116-125]
CE CBS-2161XTS—Single 3 gallon version Electrical Configurations
E216161 3 X 3.0 kW 230/400 3
3L, N+PE
8.6 12.4 22.2 [84]
E216162 3 X 4.0 kW 230/400 3
3L, N+PE
11.3 16.4 30 [114]
International, North America and Japan CBS-2162XTS—Twin 3 gallon version Electrical Configurations
Configuration
Code
Heater
Configuration
Voltage Phase Wires KW Amp Draw
Gallon/[liter]Hour
(3 gallon per batch)
E216252 6 X 3.0 kW 200-240 3 3L+G 12.6-18.1 36.4-43.7 32.4-46.5[123-176]
E216254 6 X 4.0 kW 200-240 3 3L+G 16.8-24.1 48.4-58.1 43.1-60 [163- 227]
E216291 3 X 5.0 kW 220-240/380-415 3 3L,N+G 12.7-15.1 19.3-21.0 32.6-37.8 [116-125]
E216292 6 X 3.0 kW 220-240/380-415 3 3L,N+G 15.1-18.1 22.9-25.0 38-44 [144-167]
CE CBS-2162XTS—Twin 3 gallon version Electrical Configurations
E216261 3 X 4.0 kW 230/400 3
3L, N+PE
11.3 16.4 30 [114]
E216262 3 X 5.0 kW 230/400 3
3L, N+PE
14.1 20.4 36.2 [137]
