Fetco CBS-2231 - Electrical and Output Specifications

3 P215 REV000 February 2023
Electrical and Output Specifications
Customer options
BREW BASKET TYPE
(P, M )
HOT WATER FAUCET
(M, A OR N)
BYPASS
(1 OR 0)
Brew Basket Lock
(1 OR 0)
* is factory standard feature
Add all the following numbers
after all SKU numbers
*P=Plastic
M=Gourmet Metal
*M=Standard manual
A=Automatic electronic
N=No hot water faucet
*1=With
0=None
*1=With
0=None
CBS-2231Next Gen Single 3.0-4.0 Liter Coffee Brewers Field configurable Domestic
Electrical and Output Specifications Brewer has factory installed cord and plug & terminal block 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2231US-1X117-PA011
120
1 X 1.7 kW
2+G
1.7
NEMA 15-5P
1
14.7
3.9 gal/14.8 L
Domestic-Dual Voltage
208-240
2 X 1.7 kW
2+G
2.6-3.4
Terminal Block
1
12.8-14.7
5.8 gal/22 L
Electrical Specifications, Domestic Single brewer
-single voltage 120 volt cord and plug single phase 50Hz or 60Hz
CBS-2231Next Gen Single 3.0-4.0 Liter Coffee Brewers Domestic models
Electrical and Output Specifications All brewers have factory installed cord and plug 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2231US-1A115-PA011
120
1 X 1.5 kW
2+G
1.5
NEMA 15-5P
1
13.0
4.0 gal/15.1 L
E2231US-1A123-PA012
120
1 X 2.3 kW
2+G
2.3
NEMA 5-20P
1
19.7
5.8 gal/22 L
CBS-2231Next Gen Single 3.0-4.0 Liter Coffee Brewers Field configurable NOM (Mexico) In Spanish
Electrical and Output Specifications Brewer has factory installed cord and plug & terminal block 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2231NM-1X123-PA012
120
1 X 2.3 kW
2+G
2.3
NEMA 5-20P
1
19.7
6.1 gal/23.2 L
Dual Voltage
208-240
2 X 2.3 kW
2+G
4.6
Terminal Block
1
17.1-19.7
7.6 gal/30 L
NM in SKU suffix (above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
CBS-2231Next Gen Single 3.0-4.0 Liter Coffee Brewers International models
Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2231NM-1A123-PA012
120
1 X 2.3 kW
2+G
2.3
NEMA 5-20P
1
19.7
5.8 gal/22 L
E2231NM-1A123-PA012
208-240
1 X 3.0 kW 2+G 2.3-3.0 NEMA 6-15P 1 11.3-13.0
7.9 gal/30.0 L
NM in SKU suffix
(above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
E2231IN-1B123-PA010
200-240
1 X 2.3 kW
2+G
1.6-2.3
Terminal Block
1
8.5-10.1
5.8 gal/22 L
E2231IN-1B130-PA010
200-240
1 X 3.0 kW 2+G 2.1-3.0 Terminal Block 1 10.9-13.0
7.7 gal/29.1 L
CBS-2231Next Ge n 3.0-4.0 Lit er C off ee Br ewer s CE m o dels
Elect ric al an d O utp ut Spe cifi cat ion s Sch uko cor d an d pl ug 50Hz
SKU Voltag e Heater Configuration Wir es KW Elec tri cal C on necti on Phas e Amp Dr aw Brew-V olum e per ho ur
E223 1CE-1B123-PA0 15
230
1 X 2.3 kW
L/N/ PE
2.1
CEE 7/7 Shuko
1
9.7
5.8 g al/ 22 L
E223 1CE-1B130-PA0 15 230 1 X 3.0 kW L/N/PE 2.8 CEE 7/7Shuk o 1 12.5 7.7 g al/ 29. 1 L
CBS-2232Next Gen Dual 3.0-4.0 Liter Coffee Brewers Domestic models
Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz
SKU Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2232US-1B223-PA010
208-240
2 X 2.3 kW
2+G
3.5-4.6
Terminal Block
1
17.1-19.7
11.0 gal/42.0 L
E2232US-1B223-MA110
208-240
2 X 2.3 kW
2+G
3.5-4.6
Terminal Block
1
17.1-19.7
11.0 gal/42.0 L
E2232US-1B230-PA010
208-240
2 X 3.0 kW
2+G
4.5-6.0
Terminal Block
1
22.2-25.5
14.3 gal/54 L
E2232US-1B230-PA110
208-240
2 X 3.0 kW
2+G
4.5-6.0
Terminal Block
1
22.2-25.5
14.3 gal/54 L
E2232US-1B230-MA110
208-240
2 X 3.0 kW
2+G
4.5-6.0
Terminal Block
1
22.2-25.5
14.3 gal/54 L
CBS-2232Next Gen Dual 3.0-4.0 Liter Coffee Brewers International models
Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz
SKU Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2232IN-1B223-PA010
200-240
2 X 2.3 kW
2+G
3.2-4.6
Terminal Block
1
16.5-19.7
12.2 gal/46.3L
E2232IN-1B230-PA010
200-240
2 X 3.0 kW
2+G
4.2-6.0
Terminal Block
1
21.3-25.5
15.8 gal/60 L
E2232IN-1B230-MA110
200-240
2 X 3.0 kW
2+G
4.2-6.0
Terminal Block
1
21.3-25.5
15.8 gal/60 L
E2232NM-1B230-PA010
208-240
2 X 3.0 kW
2+G
4.5-6.0
Terminal Block
1
22.2-25.5
15.8 gal/60 L
NM in SKU suffix (above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
CBS-1232PLU S Du al 3. 0-4.0 Lite r Cof fe e B rewe rs CE m od els
Elect rical an d Outp ut Spe cific ation s Al l br ewers h ave t erm in al bl oc k el ectri cal uti lity co nnec ti on 50Hz
SKU
Voltag e
Heater Configuration
Wir es
KW
Elec tric al C onn ecti on
Phas e
Amp Dr aw
Brew-V olum e per ho ur
E223 2CE-1B223-PA0 10
230
2 X 2.3 kW
L/N/ PE
4.2
Term inal Bl ock
1
18.9
11.0 gal/42.0 L
E223 2CE-1B230-PA0 10
230
2 X 3.0 kW
L/N/ PE
5.5
Term inal Bl ock
1
25.5
14.9 gal/56 L
E223 2CE-2B223-PA0 10
230/ 400
2 X 2.3 kW
2L/N/PE
4.2
Term inal Bl ock
2
9.7
11.0 gal/42.0 L
E223 2CE-2B230-PA0 10
230/ 400
2 X 3.0 kW
2L/N/PE
5.5
Term inal Bl ock
2
12.5
14.9 gal/56 L
