18 Prestige ECC Espresso Coffee Machines by fiamma - Operating Manual - 30/09/2015
3. Description
1. Control knob for steam wand
2. Manometer for the boiler pressure
3. Manometer for the pump/ water net pressure
4. Steam wand
5. Telescopic foot (height-adjustable)
6. Group
7. Automatic models (CV models): Keyboard; Semi-automatic models: Switch button
8. Porta-filter
9. Main switch (Position 1: Activation of electrical system and water filling; Position 2: Activation of the
heating elements)
10. Signal lamp for the activation of heating elements
11. Push Button for the heating of the cup warming space
12. Hot water tap
13. Control knob for water tap
14. Signal light water pump
3.1. The keyboard
AUTOMATIC MACHINES (CV MODELS)
