Fiat DOBLO 2016 - Page 222

To Next Page

To Previous Page

Flatbed long wheelbase versions

Dimensions are expressed in mm and refer to the vehicle fitted with standard tyres.

Height is measured with vehicle unladen.

ABCDEFGH I LMNOP

5416 4577 3105 911 561 1510 1845 1530 1789 1870 2405 1395 1400 600

Small variations in size are possible depending on the dimensions of the rims.

233

F0V0573

218

TECHNICAL DATA
