F0H0763m
fig. 5 - 1.6 Multijet version
1. Engine coolant
2. Engine oil
3. Brake fluid
4. Battery
5. Windscreen/rear window/headlamp
washer fluid level
ENGINE OIL fig. 6-7-8-9-10
Checking engine oil level
Check the oil level a few minutes (about
5) after the engine has stopped, with the
car parked on level ground.
The oil level shall be included between the
MIN and MAX marks on the dipstick .
The range between the MIN and MAX-
levels corresponds to approximately 1 li-
tre of oil.
fig. 6 - versions 1.2 16V - 1.4 16V
F0H0754m
Waste engine oil and oil filters
contains substances which are
dangerous for the environ-
ment. You are advised to go to
a Fiat Dealership to have the oil and
filters replaced.
