System Specifications
1. Specifications
Model FH135
82'F Air 82'F Water 82% RH
Max Heating capacity (Btu/h) 34,700
Max Power input (Btu/h) 7200
COP 5.56
60'F Air 75'F Water 65%RH
Heating capacity (Btu/h) 33440
Power input (Btu/h) 8360
COP 4.01
Power supply 110-125V/60Hz
Max power input (Btu/h) 7200
Max current (A) 15.7
Setting temperature range (Heating)
60°F～99°F
Setting temperature range (Cooling)
50°F～82°F
Running (Air) temperature range
45°F～115°F
Refrigerant type/quantity (Oz) R410A/ 16 Ozs
Air side heat exchanger Hydrophilic fin exchanger
Water side heat exchanger Titanium tube heat exchanger
Water flow (gpm) 33 GPM
Net dimension LxWxH (inch) 37 x 14 x 25
Packing dimension LxWxH (inch) 41 x 17 x 33
Net weight (lbs) 78 lbs
Packing weight (lbs)
98
Noise level dB(A) 47
Water proof level IPX4
Water pipe connection
PVC Sch 40 1-1/2”
Inlet/Outlet
The technical specification of our heat pumps is provided for informational purpose only. We
reserve the right to make change without notice in advance.
Performance varies greatly depending on the weather conditions.
1. Ratings based on US Dept Of Energy guidelines, 82-82-82 / 80-80-80/ 78-78-78
2. US Dept Of Energy recommends pool water temperatures 78, 80, or 82 Degrees.
3. FH 135 is engineered and optimized based on US Dept Energy recommendations.
4. We do not calibrate or size the heaters above 82'F pool water temperatures.
5. 55 dB noise at 10 feet, complies with Directives EN ISO 3741 and EN ISO 354
V.23.02 FIBROPOOL USA
