Sample 1
TIME 17:51:09
DATE 14.04.2009
NET 500.0kg
REF % 200.0kg
PERCENT 250.00kg
HIGH 1500.0 %
LOW 750.0 %
ABOVE LIMIT
8.2 CUSTOM PRINT OUTPUT FORMAT
40
41
Maximum 10 or 15 lines can be included for the below functions: -
 Weighing
42
(15 lines),
 Piece Count
43
(15 lines),
 Percentage
44
(15 lines),
 Animal weighing
45
(10 lines)
16 variants + 2 commands (Cr LF and End) are available for custom print
output format. Refer to the below PRINT OUTPUT FORMAT VARIANTS
TABLE for more detail.
8.2.1 To Edit Custom Print Output Format
Follow the below steps to create custom printout.
a. Go to internal function and select the desired function number to edit,
b. Select CUSTOM and press [M+],
c. This instrument displays Line 1 and the last variant or command (see
8.2.2 for details) stored,
d. Press [M+] to confirm or select other variant or command by press
40
When F18 is either set to MODE 3
41
This instrument does not support DTR (data of offline detection)
42
Set F21 = CUSTOM to edit print output format.
43
Set F22 = CUSTOM to edit print output format.
44
Set F23 = CUSTOM to edit print output format.
45
Set F24 = CUSTOM to edit print output format.
