Field Controls SWG-3 - Chimney Fan with Damper

HEARTH
Technical Service: 800.742.8368 • fieldcontrols.com 45
CHIMNEY FAN WITH DAMPER
FOR WOOD/GAS/COAL FIREPLACES
A
B
C
SPECIFICATIONS
ATAD LACIRTCELE)SEHCNI( SNOISNEMID TINU
MODELA BC DEVOLTSHzRPM HP AMPS THERMAL PROTECTION
8" DI 14 1/4819 1/217811560 1050 1/10 2.5 YES
12" DI 20 1/41219 1/2 21 12 115 60 1050 1/4 3 YES
D
E
SPECIFICATIONS
ELECTRICAL DATA
Model Volts Hz RPMs HP Amps Thermal Protection
FSGD8
12 0 60 1,050
1
⁄10 2.5 Yes
FSGD12
12 0 60 1,050
1
⁄4 3.5 Yes
DIMENSIONS
DIMENSIONS (INCHES)
Max. Hearth Opening
(sq. ft.)
Model A B C D E
FSGD8
14
1
⁄4 8 19
1
⁄2 17 8 12
FSGD12
20
1
⁄4 12 19
1
⁄2 21 12 25
A
B
C
SPECIFICATIONS
ATAD LACIRTCELE)SEHCNI( SNOISNEMID TINU
MODELA BC DEVOLTSHzRPM HP AMPS THERMAL PROTECTION
8" DI 14 1/4819 1/217811560 1050 1/10 2.5 YES
12" DI 20 1/41219 1/2 21 12 115 60 1050 1/4 3 YES
D
E
The Flue Sentinel is designed with a hinged cap so the
fan, motor, and damper are easily accessed for service
or maintenance.
Introducing the Flue Sentinel Chimney Fan with Automatic
Damper. This all-in-one includes a virtually air-tight flue damper
with a heavy duty fan and chimney cap in one convenient, high
performance package. The unit eliminates the need for glass
doors on a hearth to conserve heat, and can save as much as
30% in energy costs that would normally be caused by heat loss
through a chimney with a traditional damper.
The Flue Sentinel
®
Chimney Fan with Damper is constructed of
high-grade stainless steel and can be installed in new or pre-
existing chimneys. It is available in two sizes for chimneys with 8”
and 12” openings.
The Flue Sentinel
®
comes complete with a control kit that
interfaces with the gas logs and automatically opens the damper
and engages the fan before allowing the fire to start. Back-up
safety features ensure the fire won’t start until the damper is fully
open and draft has been proven.
FEATURES
• Stainless steel housing
• Powder-coated, stainless steel chimney cap
• Two sizes: 8" and 12"
• Easy access for service
BENEFITS
• Integrated system for easy installation
• Reliable draft to exhaust fumes and gases
• Damper reduces heat loss and downdrafts
FSGD-8 Chimney Fan
with Damper
Flue Sentinel Gas Controller
(FSGC) Included
FS TERMINATION CAP DIMENSIONS
MODEL
DIMENSIONS (INCHES)
A B C
8" TERMINATION CAP
12.75 7.38 7.95
10" TERMINATION CAP
14.75 7.76 9.95
12" TERMINATION CAP
20.75 11 . 2 0 11 . 9 5
14” TERMINATION CAP
23 11.83 13 .95
TERMINATION CAP
