Fiessler AKAS-3PM - Status Messages and Error Reporting

The AKAS® displays messages by serial transfer via its RS 232 interface; transfer format: 9600 baud, 1 start
bit, 8 data bits, 1 stop bit. The messages have even parity and will be repeated at least three times. The time
gap between 2 messages is at least 100 ms. At the receiver, defective messages are gated, because only tho-
se messages are accepted that fullfill the following conditions: an even parity, successful reception of the mes-
sage is provided if it is received at least 3 consecutive times and if its complete compatibility to one of the mes-
sage possibilities indicated below is given.
There are different kinds of messages:
- Information concerning the status of the AKAS® or handling directions for the operator,
here are Bit 0 and Bit 1 = 1,
- Warnings concerning errors that, if received three times one immediately after the other, may lead to the in-
terlocking of the AKAS®, here is Bit 0 = 0 and Bit 1 = 1,
- Error reports of the interlocked AKAS® , here is Bit 0 = 1 and Bit 1 = 0.
Electrical connections - Description / Wiring diagrams
Displaying outputs
39
Status messages,
warnings and Error
reports via the RS 232
serial interface
Status messages, handling di-
rections for the operator
(binary xxxxxx11)
6
6.5
message
transferred
byte
decimal
operating mode
description
possible text in the display sy-
stem
handling directions
3
3
antivalent foot pedal
inputs without pro-
tective circuit monito-
ring
front reset button does not
enable
normally closed contact of
the foot pedal does not
enable
verify reset button and cable leading to the normally
closed contact of the foot pedal if interrupted
verify the cable leading to the normally closed con-
tact of the foot pedal if interrupted
3
7
11
15
equivalent foot pe-
dal inputs
error at the request for
release of the closing stroke
Mutinglamp does not light up
only AKAS...P
SP too early
Stop at the overrun traver-
se cam
check the equivalent switching lines going FUO and
FUS . They are evaluated as "different"
see message 63
Before the SP input is activated the receiver element E2 re-
spectively E4 must be interrupted by the Fiessler magnet pla-
te. Set the SP output of your machine to a corresponding
value.
during overrun traverse test
15
23
27
39
without overrun
traverse control
-
open the press completely
in order to quit the safety
point range
only AKAS...P
E3 interrupted
release foot pedal
43
43
51
51
without overrun
traverse control
overrun traverse OK
-
without EDM
rear reset button is defective or
the EDM is not in Stop status
rear RESET button is de-
fective
-
if this message is displayed after every pressing and
releasing of the foot pedal, check the SP connecting
circuit for short circuits
Check whether slowspeedsignal comes after
Interrupting the E3
during overrun traverse test
-
check rear reset button for short-circuits
check rear reset button for short circuit
51
51
63
71
without protective
circuit monitoring
without EDM and
without protective
circuit monitoring
EDM is not in Stop Status
wrong potential at EDMO
or EDMS
only AKAS...P
Mutinglamp does not light
up
max. fastspeed exceeded
83
83
95
95
without overrun
traverse control
overrun traverse too long
-
without overrun
traverse control
overrun traverse mearue-
ment has not been carried
out
-
Check EDM Signals
check the connectors for short circuits
open the press completely. If this message is repeated at the
following new stroke and the internal muting lamp does not
light up,there is an internal error at the version that has no
connection option of an external muting lamp. With the ver-
sion with external connection option of an external Muting
lamp, the connection KAST must be checked for short-circuits
on -.
Check whether slowspeedsignal comes later than
800ms after controlling SP
during overrun traverse test
-
possible reasoin: the protective field is interrupted, or the pro-
tective circuit is interrupted, or the foot pedal is released, or
no fast speed during the overrun traverse measurement, evtl.
because the stroke for the oberrun traverse measurement
has not been started by the UDC of the machine. Open the
press completely and carry out a new stroke for the overrun
traverse measurement.
-
background grey:
other message or
no message, if mo-
nitoring functions
are partially cancel-
led
FIESSLER
E L E K T R O N I K
Doku Nr. 1379 Stand 27.1.2017 /Aui
