Fiessler AKAS-3PM - AKAS Protection Limitations

S3
WARNING:
Safety Instructions
SI
No protection by AKAS
®
No protection by AKAS
®
PictureS3/3



PictureS3/1
No protection by AKAS
®
PictureS3/2
WARNING: The pressbrake sa-
fety system AKAS
®
does not pro-
tect against all
movements of the backgauge.
WARNING: The pressbrake sa-
fety system AKAS
®
does not
protect against the
movements of the dynamic
sheet support.
WARNING: The shelters that protect the
worker getting inside the pressbrakes
danger-zone have to be modified in a way
that there are no possibilities to get inside
in the danger-zone and to get squeezed
between the machine, the safety equip-
ment and parts or material.
WARNING: The distance bet-
ween the front edge of the
AKAS
®
systems and the
pressbrake should be >100mm
to avoid injuries while while
closing the press.
(see also Fig. 20/ 1)
No protection by AKAS
®
PictureS3/4
No protection by AKAS
®
PictureS3/5
No protection by AKAS
®
PictureS3/6
dynamic sheet support
No protection by AKAS
®
PictureS3/7

























































backgauge
No protection by AKAS
®
PictureS3/8
No protection by AKAS
®
PictureS2/9
> 20mm
AKAS
®
WARNING: The pressbrake sa-
fety system AKAS
®
does not pro-
tect against bending punches
larger than 40 mm from the ben-
ding line.
WARNING! Read and understand this section prior to installing and operating
the system AKAS
®
Please observe always
No protection by AKAS
®











PictureS3/10
WARNING: The pressbrake sa-
fety system AKAS
®
provides not a
full protection when slipping with
finger or hand on the upper edge
of a box wall during the down-
wards of the upper die. When the
receiver element is already below
the upper edge.
box
wall
FIESSLER
E L E K T R O N I K
Doku Nr. 1379 Stand 27.1.2017 / Aui
No protection by AKAS
®
WARNING: The pressbrake sa-
fety system AKAS® does not pro-
tect If the lateral die cover is
higher than the top of the die
and the blanking signal (SP) is
set to this wrong position of the
leteral die cover together with a
wrong SP setting
leteral die cover
