INSTALLATION AND OPERATION MANUAL
| 900CD DIGITAL METER
If in doubt about compatibility of a specific fluid, contact supplier of fluid to check for
any adverse reactions to the following wetted materials:
Aluminum, Stainless Steel, Fluorocarbon, Polyester, Nickel, Acetal.
CAUTION
Figure 1
Fluid Compatilibity
The 900CD Series Meter IS compatible with the following fluids:
Diesel Fuel, Bio-Diesel (up to B20), Mineral Spirits, Heptane, Hexane, Gasoline, E15
The 900CD Series Meter IS NOT compatible with the following fluids:
Bleach, Hydrochloric Acid, Ink, Sulfuric Acid, Salt Water
Assembly and Disassembly
The 900 Series Digital Meter consists of a chamber housing, measuring chamber, drive shaft, digital counter assembly,
and cover. The design of the meter is such that it can be completely disassembled without disturbing the piping (refer
to diagram on page 9 for item number parts).
Accessing the Battery
For access to the batteries (2 AA batteries) (Figure 1):
1. Remove the four screws at the top and bottom of the front bezel (Torx #T25).
2. Lift bezel off. Batteries are located on the back side of the display; use a Phillips head screwdriver to remove
the cover to access the batteries.
3. Reassemble by reversing this procedure.
To reduce the risk of explosion DO NOT mix old batteries with new batteries, or mix
batteries of different manufacturers.
WARNING
Batteries may ONLY be replaced with the following:
• Duracell MN1500 • Duracell MX1500 • Energizer E91
WARNING
To reduce the risk of ignition of a flammable explosive atmosphere, batteries MUST be
changed ONLY in a location known to be non-hazardous.
WARNING
