Lens Type Varifocus 3–9 mm MggaPixel Lens , F1.4
Sensitivity
Color : 0.1Lux AGC ON
B / W: 0.05 Lux AGC ON
Support DC IRIS Yes
Shutter Time Indoor, Outdoor, 1/30 ~ 1/1000
ICR Mechanism IR cut Filter (optional)
LED
Built-in 18 units IR LED
IR Distance-15M
I/O 1 Alarm in / 1 Relay out
Audio G.711(64K) and G.726(32K,24K) audio compression
Input : External Mic in
Output: External Audio out
Power over Ethernet Yes
Operating Temperature -10°C ~ 45°C
Dimensions 126mm (W) x 126mm (L) x 100mm (D)
Weight 1300 g
Network
Ethernet 10/ 100 Base-T
Network Protocol HTTP, HTTPS, SNMP, QoS/DSCP, Access list, IEEE
802.1X, RTSP, TCP/ IP, UDP, SMTP, FTP, PPPoE, DHCP,
DDNS, NTP, UPnP, 3GPP, SAMBA, Bonjour, IPv4, IPv6
System
Video Resolution
1920x1080@30fps, 1280x720@30fps, ,640x480@30fps,
320x240@30fps, 176x144@30fps
Video Adjust Brightness, Contrast, Hue, Saturation, Sharpness, Shutter
Speed, AGC, Sense-Up, D-WDR,Flip, Mirror, Noise
reduction, Exposure, Day&Night
Triple Streaming Yes
Image snapshot Yes
Full screen monitoring Yes
Privacy Mask Yes, 3 different areas
Compression format H.264/ M-JPEG/ MPEG4
Video bitrates adjust CBR, VBR
Motion Detection Yes, 3 different areas
Triggered action Mail, FTP, Save to SD card, Relay out, SAMBA
Pre/ Post alarm Yes, configurable
