USB pORT
To upload/download users informa-
tion, password, fingerprints and
transaction logs via USB flash disk.
USB port for data transfer
The L.E.D display has two lights.
Green - The reader is in standby mode or to indicate that
user has been successfully verified.
Red - To indicate that user verification has failed.
COLOR LCD
Screen that displays instruction
and status of terminal.
OpTICaL SCaNNER
For user to place finger for
enrollment or verification.
NavIGaTION kEyS
To navigate and to input
command to terminal.
SpEakER
To prompt user with result of
verification and information.
FUNCTION kEyS
Shortcut keys to enter
specific command to
terminal.
kEypaDS
Keys from 0-9, alphabets Power
on/off button, Escape/Cancel
button, Menu/Enter button,
backspace button, asterisk (*)
button, hash (#) button.
CaRD
RFID card induction area.
Escape
Menu/Enter
Backspace
Power On/Off
Asterisk Hash
To Next Page
