LUBRICATION CHART
Ref. No. Location Lubricant Frequency Number
1 Airlock Bearing CL Weekly 2
2 Change Air Lock Gearbox Oil GO 50,100, 1
then Seasonally
3 Feeder Roll Bearing CL Weekly 1
4 Floor Pillow Block Bearing CL Weekly 1
5 Floor Take-Up Bearing CL Weekly 2
6 Check Blower Inlet Filter Daily 1
7 Check Engine Air Cleaner Daily 1
8 Check Engine Coolant Level AF Daily 1
Change Engine Coolant AF Seasonally 1
9 Change Engine Oil and Filter HO See Engine Manual 1
10 Check Engine Oil Level HO Daily 1
11 Check Fuel Level DF Daily 1
12 Check Hydraulic Oil Level HO Daily 1
Change Hydraulic Oil and Filter HO Seasonally 1
13 Check Blower Oil Level BO Daily 2
Change Blower Oil BO 50,100, 2
then Seasonally
14 Agitator Bearing CL Weekly 1
15 Change Floor Drive Gearbox Oil GO 50,100, 1
then Seasonally
16 Change Agitator Gearbox Oil GO 50,100, 1
then Seasonally
17 Check Chain Tension Weekly 1
Lubricate Floor Chain CH Seasonally 1
18 Airlock Shaft Seals CL Weekly 2
TIME KEY
DAILY (8 hours)
WEEKLY (50 hours)
SEASONALLY (500 hours)
SEE ENGINE MANUAL
LUBRICANT OR FLUID USED
CL Chassis Lubricant
BO Blower Oil Mobil SHC-630 Synthetic
AF 50/50 Antifreeze and Water Mixture
DF Number 1-D / Number 2-D Diesel Fuel
HO Hydraulic Oil DTE-13M Hyd. Fluid
GO SAE 80W90 Gear Oil
CH Mineral Oil or Chain Lubricant
FLUID CAPACITIES
Fuel - 38 gal (143.8 L) Agitator Gearbox Oil - 2 qt (1.89 L)
Hydraulic Oil - 36 gal (136.2 L) Airlock Gearbox Oil - 20 oz (0.59 L)
Engine Coolant - 4 gal (15.1 L) 50/50 Mix Only Floor Gearbox Oil - Fill to Level Plug
Engine Oil - See Engine Manual Blower Oil - See Blower Manual
