57
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
CONTROL BOX HARNESS
Part Number Description No. Req'd
053060 Control Box Wiring Harness
1 053017 Deutsch #HD36-24-31ST 1
2 053042 Deutsch #34-18-14PT Receptacle 1
3 170019 SINGLE CIR RECEPT HSG 480054-3 5
4 170023 FASTON RECEPT #42282-2 5
5 170101 Deutsch #HDP26-24-21SE Plug 1
6 190051 WIRE 16GA BLACK SAE SXL 48"
7 190051 WIRE 16GA BLACK SAE SXL 59"
8 190051 WIRE 16GA BLACK SAE SXL 100"
9 190058 WIRE 16GA ORANGE SAE SXL 37"
10 190108 16 CONDUCTOR SDN CABLE 96"
11 190146 16 GA./3 Conductor SOW-A Cable 242"
12 190228 Datacell 1939 TF Can-Bus Cable 242"
13 170111 Deutsch Socket (16 Ga.) 41
14 170112 Deutsch Socket (12 Ga.) 2
15 170110 Deutsch Socket (16 Ga.) 24
ELECTRICAL COMPONENTS NOT INCLUDED IN HARNESSES
023814 Electric Throttle Actuator 1
FW71978 Fuel Level Sender 1
007706 Oil Gauge 1
008473 Oil Line Kit 1
021839 Temperature Gauge 1
012537 Temperature Adapter Kit 1
FW71972 Fuel Gauge 1
JDRE54092 Engine Starter 1
JDTY24485 95A Alternator 1
022891 Solenoid Relay 1
011851 12-Volt Battery 1
031031 Battery Cable 1
010516 Ground Strap 1
011770 Battery Box 1
FW75186 Hydraulic Oil Cooler w/Fan 1
FW75186-F Fan Only 1
To Next Page
