Finn BarkBlower BB-1208 MS - Page 64

58
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
VALVE WIRING HARNESS
2 Conductor Cable - 2
2 Conductor Cable - 1
White White White White White White White White White
9 9
Agitator Pressure Switch Airlock Pressure Switch
A
B
2 Conductor Cable - 11
Black
White
A
B
Black
White
Black
White
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Flasher
Airlock Pressure Switch
Agitator Pressure Switch
Pressure Switch and
Air Lock Proportional Sol.
Floor Proportional Sol.
Air Lock Reverse Sol.
Floor Reverse Sol.
Agitator Forward Sol.
Agitator Reverse Sol.
SI Forward Sol.
SI Reverse Sol.
SI Motor -
SI Motor +
Safety Switch Power
Green
Black
White
3 Conductor Cable - 9
Black
Green
White
1
2
3
4
9
11 11
5
6
7
8
10
2 Conductor Cable - 11
Black Black Black Black Black Black Black Black Black Black
White
2 Conductor Cable - 10
2 Conductor Cable - 8
2 Conductor Cable - 7
2 Conductor Cable - 6
2 Conductor Cable - 5
2 Conductor Cable - 4
2 Conductor Cable - 3
Wire DIN connector plug as shown. Black wire from 16/2 cable should connect to the terminal next to the light. White wire is then opposite terminal. NOT to the ground terminal.
DIN CONNECTOR WIRING
HH PP
HH PP
x4
3B
1
21
A
19
18
9
17
16
15
14
13
12 11
10
20
FF MM HH PP
Light
Hot
(Black)
Common (White)
When Used (Green)
A
B
C
D
E
F
G
H
J
K
L
M
N
P
A
22
2
2
22
20
18
19
9
21
17
16
15
14
13 12 11
10
