ASSEMBLE BURNERS AND CHECK IGNITION
The electrode of the electronic ignition system is positioned above the surface of the burner base. Do not remove a
burner cap or touch the electrode of a burner while another is turned on. Damage or electrical shock may occur.
The electrode of the electronic ignition system is positioned above the surface of the burner base. Do not remove a
burner cap or touch the electrode of a burner while another is turned on. Damage or electrical shock may occur.
Place burner heads over the burner base. Make sure the hole in the burner head is properly aligned with the elec-
trode in the burner base.
Place the burner caps on the burner heads. Make sure that the burner caps are properly seated on the burner heads.
Burner cap properly seated Burner cap not properly seated
Check igniters.
Operation of the electric igniters should be tested after the cooktop and supply line have been carefully checked for
leaks and the cooktop has been connected to the electrical power.
Push and turn a burner valve to the LITE position. All spark igniters will make a series of sparks (ticking sounds),
but only the burner turned to LITE will light.
The burner should light when gas is available to the burner.
Once the burner lights, it should be turned to another position.
Test each valve separately until all burners have been checked.
IMPORTANT: If the igniter electrodes continue to spark after all of the burners are lit, check that each burner
com- ponent is assembled and properly seated.
