Programming
MS-9050UD Series PN 52413:D 12/15/08 109
ANN-I/O Point Option
If Point is selected as the module option, the first ten LED driver outputs on the first ANN-I/O
module will display the system status information. The remaining 30 LED driver outputs on the
first module and 20 LED driver outputs on the second module will be used to display the active/
alarm status of each point in the Point Range programmed for that particular module. The
points that will be annunciated on a particular ANN-I/O module depend on the programming
options selected as far as the device type (detector or module) to be annunciated. The LED
assignments for each ANN-I/O module will be as follows.
ANN-I/O Module #1 ANN-I/O Module #2
Module LED Function Function
1AC Fault Not Used
2 Fire Alarm Not Used
3 Supervisory Not Used
4 Trouble Not Used
5 Alarm Silenced Not Used
6 Not Used Not Used
7 Not Used Not Used
8 Not Used Not Used
9 Not Used Not Used
10 Not Used Not Used
11 Point 01 - Active/Alarm Point 31 - Active/Alarm
12 Point 02 - Active/Alarm Point 32 - Active/Alarm
13 Point 03 - Active/Alarm Point 33 - Active/Alarm
14 Point 04 - Active/Alarm Point 34 - Active/Alarm
15 Point 05 - Active/Alarm Point 35 - Active/Alarm
16 Point 06 - Active/Alarm Point 36 - Active/Alarm
17 Point 07 - Active/Alarm Point 37 - Active/Alarm
18 Point 08 - Active/Alarm Point 38 - Active/Alarm
19 Point 09 - Active/Alarm Point 39 - Active/Alarm
20 Point 10 - Active/Alarm Point 40 - Active/Alarm
21 Point 11 - Active/Alarm Point 41 - Active/Alarm
22 Point 12 - Active/Alarm Point 42 - Active/Alarm
23 Point 13 - Active/Alarm Point 43 - Active/Alarm
24 Point 14 - Active/Alarm Point 44 - Active/Alarm
25 Point 15 - Active/Alarm Point 45 - Active/Alarm
26 Point 16 - Active/Alarm Point 46 - Active/Alarm
27 Point 17 - Active/Alarm Point 47 - Active/Alarm
28 Point 18 - Active/Alarm Point 48 - Active/Alarm
29 Point 19 - Active/Alarm Point 49 - Active/Alarm
30 Point 20 - Active/Alarm Point 50 - Active/Alarm
31 Point 21 - Active/Alarm Not Used
32 Point 22 - Active/Alarm Not Used
33 Point 23 - Active/Alarm Not Used
34 Point 24 - Active/Alarm Not Used
35 Point 25 - Active/Alarm Not Used
36 Point 26 - Active/Alarm Not Used
37 Point 27 - Active/Alarm Not Used
38 Point 28 - Active/Alarm Not Used
39 Point 29 - Active/Alarm Not Used
40 Point 30 - Active/Alarm Not Used
