Programming
MS-9050UD Series PN 52413:D 12/15/08 59
When the last digit is keyed-in, if the selected address has not been added to programming, a
screen showing information about a device that is
installed with a lower address, closest to the
selected address, will be displayed.
If no
detectors have been installed on the loop, the following will be displayed:
If the selected address has been added to programming, device summary screens will be
displayed. These screens allow the programmer to view all device settings at a single glance.
Pressing the left or right arrow keys will allow the programmer to rapidly view the devices at
the previous or next address (if installed).
If a detector (such as a photoelectric detector) with the selected address is not physically
installed on the SLC or has a communication fault but the address is programmed in the system,
the following screen will be displayed:
If the selected address has been added to programming and a detector (such as a photoelectric
detector) with the selected address is physically installed on the SLC and is communicating
with the control panel, the following will be displayed:
To change the programming for the displayed detector, press the keyboard ‘down’ arrow key to
view the Edit Detector screens.
In the preceding example:
Normal - indicates that the detector with the selected address is physically installed on the
SLC and communicating with the control panel (enabled)
<ADJ><NOUN> - represents the adjective and noun, which have been programmed,
describing the location of the displayed device
ZNNN - represents the first of five possible software zones that the detector is assigned to
(NNN = the three digit zone number from 000 - 019)
V or * - indicates whether or not alarm verification is enabled (V = alarm verification
enabled and * = alarm verification disabled)
1D017 - represents the Loop, Device type and Device address (1 = SLC Loop, D=Detector
and 017 = Detector Address 017)
NO DETECTOR
INSTALLED
Edit Detector Screen #1
TROUBL SMOKE(PHOTO)
<ADJ><NOUN>
ZNNN
* 1D017
Edit Detector Screen #1
NORMAL SMOKE (PHOTO)
<ADJ><NOUN>
ZNNN
V 1D017
Edit Detector Screen #1
