When the last digit is keyed-in, if the selected address has not been added to programming, a
screen showing information about a device that is
installed with a lower address, closest to the
selected address, will be displayed. If no modules are installed on the loop, the following
screen will be displayed:
If the selected address has been added to programming but a module (such as a monitor
module) with the selected address is not physically installed on the SLC or has a
communication fault, the following screen will be displayed:
If the selected address has been added to programming and a module (such as a monitor
module) with the selected address is physically installed on the SLC and is communicating with
the control panel, the following screen will be displayed:
To change the programming for the displayed module, press the keyboard down arrow key to
view the following Edit Monitor screens. In the preceding example:
Normal - indicates that the module with the selected address is physically installed on the
SLC and communicating with the control panel (enabled)
<ADJ><NOUN> - represents the adjective and noun, which have been programmed,
describing the location of the displayed device
ZNNN - represents the first of five possible software zones that the module is assigned to
(NNN = the two digit zone number from 000 - 019)
1M012 - represents the Loop, Device type and Device address (1 = SLC Loop 1,
M=Module and 012 = Module Address 012)
W or * - indicates whether or not the device is programmed for Walktest (W =
programmed for walktest, * = not programmed for walktest).
NO MODULE
INSTALLED
Edit Module Screen
TROUBL MONITOR
<ADJ><NOUN>
ZNNN
* 1M012
NORMAL MONITOR
<ADJ><NOUN>
ZNNN
W 1M012
To Next Page
