MS-9600LS Series Manual — P/N 52646:B8 11/20/2015 173
Canadian Applications
FIRE SYSTEM
ACTIVE
SYSTEM
CONTROL
ALL
CALL
1
2
3
4
5
6
7
8
9
10
11
12
13
18
19
20
21
22
23
24
16
17
14
15
LIT
FI
®
AL
by Honeywell
Figure G.2 FACP Maximum Configuration - Eight ANN-LED Annunciators
metal conduit
(max. 20 ft.)
FACP
ANN-LED Annunciators
ANN-LED annunciators must
be in same room as FACP
Optional ECC-50/100
Audio System
ms-9600lstoann_led8.wmf
When using an audio system,
7 ANN-LEDs can be used.
