MS-9600LS Series Manual — P/N 52646:B8 11/20/2015 81
Master Programming Level Programming
Pressing 1 while viewing the Noun/Adjective Screen will cause the following screen(s) to be dis-
played. Note that the keyboard down arrow key must be pressed to see all the Adjective screens.
Press the number corresponding to the adjective that is to be used as a descriptor for the location of
the monitor module currently being programmed.
Pressing 2 while viewing the Noun/Adjective Screen will cause the following screen(s) to be dis-
played. Note that the keyboard down arrow key must be pressed to see all the Noun screens. Press
the number corresponding to the noun that is to be used as a descriptor for the location of the mon-
itor module currently being programmed.
Pressing 3 or 4 while viewing the Noun/Adjective Screen will display screens similar to the previ-
ous Adjective and Noun Screens. The new screens will list Custom Adjectives and Nouns which
have been programmed into the control panel using the PS-Tools programming kit.
1=STANDARD ADJECTIVE
2=STANDARD NOUN
3=CUSTOM ADJECTIVE
4=CUSTOM NOUN
Noun/Adjective Screen

1=NORTH
2=SOUTH
3=EAST
Adjective Screen #1

1=WEST
2=FRONT
3=CENTER
Adjective Screen #3

1=REAR
2=UPPER
3=LOWER
Adjective Screen #5

1=MAIN
2=FIRST
3=2ND
Adjective Screen #7

1=3RD
2=4TH
3=5TH
Adjective Screen #2

1=FLOOR 4
2=FLOOR 5
3=ROOM
Adjective Screen #6

1=FLOOR 1
2=FLOOR 2
3=FLOOR 3
Adjective Screen #4
1=STANDARD ADJECTIVE
2=STANDARD NOUN
3=CUSTOM ADJECTIVE
4=CUSTOM NOUN
Noun/Adjective Screen

1=BASEMENT
2=BOILER RM
3=CLASSROOM
Noun Screen #1

1=CLOSET
2=CORRIDOR
3=ELECTRIC RM
Noun Screen #3

1=ELEVATOR
2=ENTRANCE
3=FLOOR
Noun Screen #5

1=GARAGE
2=HALLWAY
3=HVAC RM
Noun Screen #7

1=KITCHEN
2=LOBBY
3=OFFICE
Noun Screen #2

1=STAIRWAY
2=STOREROOM
3=WING
Noun Screen #6

1=PATIENT
2=RESTROOM
3=ROOM
Noun Screen #4

1=ZONE
Noun Screen #8
