7.6.2.4 8150 series Horizontal Split Case maximum forces and moments allowed
Size
Maximum forces (F) in lbf (N) and moments (M) in lbf.ft (Nm)
Suction Discharge
F
x
F
y
F
z
M
x
M
y
M
z
F
x
F
y
F
z
M
x
M
y
M
z
16X10X22
623 779 323 865 1081 2163 196 245 160 207 259 518
(2771) (3465) (1437) (1173) (1466) (2933) (872) (1090) (712) (281) (351) (702)
