Table 16 List of components 8200 Horizontal Split Case Fire pump
Cat. No. Description Qty Cat. No. Description Qty
1-952-0 Bleed Line 1 3-026-4 Bearing, Outboard 2
1-952-0 Flush Line 1 5-050-4 Split Ring 1
0-910-9 Pipe Plug 14 5-421-4 Retaining Collar 1
1-013-9 Seal Cage 2 3-169-9 Deflector 2
1-014-9 Gland 2 3-177-9 Lip Seal 2
1-901-9 Gland Bolt 4 3-516-4 Locknut 1
1-909-9 Washer, Gland Bolt 4 3-514-4 Lockwasher 1
1-924-9 Packing Ring 10 3-902-9 Set Screw 2
2-001-7 Casing, Upper Half 1 5-904-9 Bearing Cover Bolt 8
2-001-8 Casing, Lower Half 1 3-911-1 Key (Impeller) 1
2-123-5 Gasket, Casing (Suction) 1 3-911-2 Key (Coupling) 1
2-123-6 Gasket, Casing (Discharge) 1 3-914-9 O-Ring (Shaft Sleeve) 2
2-904-1 Cap Screw (Casing) VARIES 3-914-9 O-Ring (Stuffbox Bushing) 4
1-439-0 Dowel 2 6-008-0 Stuffbox Bushing 2
3-003-9 Casing Ring Assembly 2 3-034-0 Interstage Bushing 1
3-007-0 Shaft 1 3-231-0 Interstage Diaphragm 1
3-009-9 Shaft Sleeve 2 3-914-7 O-Ring (Interstage Bushing) 3
3-015-9 Shaft Sleeve Nut 2 5-915-0 Snap Ring (Bearing) 1
5-018-0 Bearing Housing Cover 2 3-915-0 Snap Ring (Interstage Bushing) 1
3-025-3 Bearing Housing 1 4-002-0 Impeller 2
3-026-3 Bearing, Inboard 1
Bold Face: Recommended spare parts
