AC6102 Rev 03 46
Table 17 List of components 9100 Horizontal Split Case Fire pump
Cat. No. Description Qty Cat. No. Description Qty
0-901-0 Valve 2 3-015-9 Shaft Sleeve Nut 2
0-910-0 Pipe Plug 20 3-018-3 Bearing Housing Cover (Inboard) 1
0-950-0 Pipe Nipple 2 3-018-4 Bearing Cover (Outboard) 1
0-952-0 Tubing 2 3-025-2 Bearing Housing 2
1-013-2 Seal Cage 2 3-026-2 Bearing 2
1-014-2 Gland 2 3-078-9 Thrust Washer (Outboard) 1
1-333-1 Bearing Isolator 3 3-177-4 Lip Seal (Outboard Bearing) 1
1-904-9 Gland and Housing Bolt 12 3-409-9 Gasket (Bearing Housing Cover) 2
1-909-9 Washer, Gland Bolt 4 3-516-4 Locknut 1
1-924-9 Packing Ring 12 3-517-4 Lockwasher 1
2-001-7 Casing, Upper Half 1 3-902-9 Set Screw (Shaft Sleeve Nut) 2
2-001-8 Casing, Lower Half 1 3-904-9 Gland and Cover Bolt 4
2-123-5 Gasket, Casing (Suction) 1 3-911-1 Key (Impeller) 1
2-123-6 Gasket, Casing (Discharge) 1 3-911-2 Key (Coupling) 1
2-904-1 Cap Screw (Casing) VARIES 3-911-3 Key (Shaft Sleeve) 2
2-916-9 Taper Pin 2 3-914-9 O-Ring (Shaft Sleeve) 2
3-003-9 Casing Wear Ring 2 3-915-9 Snap Ring 2
3-007-0 Shaft 1 3-943-9 Spirol Ring 2
3-009-9 Shaft Sleeve 2 4-002-0 Impeller 1
Bold Face: Recommended spare parts
