Table 18 List of components 8150 Horizontal Split Case Fire pump
Cat. No. Description Qty Cat. No. Description Qty
2-001-0 Casing Asm 125Flg DI 1 3-025-3 Housing Bearing Inboard 1
2-001-0 Casing Asm 250Flg DI 1 3-025-4 Housing Bearing Outboard 1
2-001-0 Casing Asm 125-250Flg DI 1 3-904-9 CAPSCREW 3/8-16UNCX3-1/2 8
0-905-0 Grease Fitting 2
0-910-9 Pipe Plug 1/2NPT Brass 2 3-904-8 CAPSCREW 1/2-13NCX1-1/2 8
0-910-8 Pipe Plug 1NPT SS 2
0-910-7 Pipe Plug 1/4NPT SS 8 2-904-1 BOLT, CASING 1-8UNCx2.75 12Pt 42
2-904-2 BOLT, CASING 1-8UNCx7 12Pt 4
2-123-5 Gasket: Suction, Casing 1 2-916-1 PIN, TAPER 2
2-123-6 Gasket: Discharge, Casing 1
6-924-0 Packing 5/8 10
3-007-0 Shaft 1 6-013-2 Lantern Ring 2
4-002-0 Impeller Brz w/o rings 1 6-014-0 Gland 4
3-911-1 Impeller Key 1/2x5-3/4 1 6-902-2 Capscrew 1/2-13UNCx2-1/2 SS 4
3-009-2 Shaft Sleeve 2 0-909-0 Washer 1/2 4
3-914-9 O-Ring Sleeve 2-153 (3.500x.103) 2
3-015-9 Shaft Sleeve Nut 2 0-952-1 HEX BUSHING 1/2NPT x 1/4NPT 1
3-902-3 Setscrew 1/4-28UNFx3/16 SS 4 0-952-2 NIPPLE 1/4NPT x 1-1/2 1
3-136-9 Slinger 2 0-952-3 TEE 1/4NPT 1
3-003-2 Ring Casing: Brz 2 0-952-4 NEEDLE VALVE 1/4NPT-1/4TUBE 2
3-943-9 Pin W/R 2 0-952-5 TUBING 1/4 COPPER 4
0-952-6
CONNECTOR MALE COMP
1/4ODX1/4NPT
2
3-177-2 Lip Seal 2
3-025-5 Bearing Bracket 2 3-911-2 Coupler Key 3/4x3/4x4.5 1
0-915-0 Snap Ring Bearing 2
3-026-2 Bearing 6316 w/Shield 2
3-177-3 Snap Ring Beveled 1
Bold Face: Recommended spare parts.
