Firebird Condensing Boiler
The boiler is factory fitted with a burner control box lockout safety feature which operates automatically if a fault
occurs in the burners operation. Should this occur, the light on the front of the burner (see photo below or burner
manual) will illuminate and its cause must be investigated.
This could be caused by:
A. An interruption in the fuel supply. (Eg. empty oil supply tank or clogged filter)
B. An electrical supply fault.
C. A fault with the burner or its safety control system.
D. The failure of a component. (Eg. photo cell)
E. Worn or dirty oil nozzle.
Before attempting to restart the boiler, the front panel (Utility boiler only) and the burner cover should be removed
and a visual check should be made for any obvious problems with burner such as oil leaks, loose connections etc.
ENSURE OIL TANK CONTAINS CORRECT GRADE FUEL NO. 2 OIL
DO NOT START BURNER UNLESS ALL CLEANOUT DOORS ARE SECURED IN PLACE
DO NOT ATTEMPT TO START THE BURNER WHEN EXCESS OIL HAS ACCUMULATED, WHEN
THE UNIT IS FULL OF VAPOUR, OR WHEN THE COMBUSTION CHAMBER IS VERY HOT
TO RESTART THE BOILER
1. Press reset button once only, see photo below.
2. Ensure that the boiler thermostat, room thermostat and any external controls
connected to the boiler are set to call for heat.
3. Check that the oil tank valves are open and there is sufficient oil in the tank.
4. Check that the burner lockout light is unlit and with the ‘main switch ON’,
the boiler will be ready to begin its start sequence.
1
4
HOMEOWNER INSTRUCTIONS
BURNER LOCKOUT
