"FWxxyyzz.bin"
- FW
- xx is a major release number
- yy is a minor release number
- zz is a test release number
- .bin
Rename the file to this format if it's not
done already.
2. Get a FAT or FAT32 USB pen drive.
3. Create a folder named ‘F_FW’ at the root of
the USB pen drive.
4. Copy the downloaded file into the ‘F_FW’
folder.
5. Insert the USB pen drive on a working panel.
6. Click on the 1=Program menu and select
option 7=USB followed by option 5=FW
Upgrade.
7. Wait until the panel returns to the main
page. This procedure takes a few minutes to
complete.
Note: The upgrade procedure may take
several minutes to complete
FC503 and FC506 Addressable Fire Control Panels82
