17
4.1 System Maintenance
The system will automatically compensate for dust build-up by changing the Compensation Level. However, it is
recommended that the Transmitter and Receiver lenses are cleaned periodically with a soft lint-free cloth. The
system should be isolated from the Fire Control Panel before cleaning takes place. After cleaning, verify that the
system is operating normally by following the Alignment procedure and the Fire and Fault Tests described in this
User Guide.
4. Maintenance and Troubleshooting
Error
C
ode
Meaning Corrective Action
E-00 AIM not recognised Refer to manufacturer for further technical
a
ssistance
E-01 Receiver Communications Fault Check wiring between Controller and
Receiver
E-02 ‘Find’ not successfully executed Follow ‘Find’ process
E-03 Compensation limit reached Clean and re-align system
E-04 Receiver missed too many readings, or lost sync
w
ith the Transmitter
Ensure clear line of sight from Transmitter to
R
eceiver
E-05 Receiver is not aligned Follow alignment procedure
E-06 Rapid Obscuration Fault Ensure clear line of sight from Transmitter to
Receiver
E-07 Signal High Fault Ensure there is no stray light from another source
E-15 Signal too low at end of alignment Ensure clear line of sight from Transmitter to
Receiver. Ensure alignment of Transmitter AND Receiver. Do not exit
whilst alignment status LEDs are still flashing
E-16 Signal too high at end of alignment Follow alignment procedure again. Do not exit
whilst alignment status LEDs are still flashing
E-18 Short circuit detected on communications
between Controller and Receiver
Check wiring between Controller and Receiver
E-19 IR signal integrity fault Check there are no strong sources of light near the Receiver, or direct
sunlight
E-20 Ambient light fault Check there are no strong sources of light near the Receiver, or direct
sunlight
E-21 Power too low fault Check power supply to Controller
4.2 Error Codes
