Fireray 3000 User Manual

25
9. Approval Information
9.1 UL Approval Information
9.2 European Approval Information
• UL File Number: S3417
• All installations should comply with NFPA72. No liability will be accepted for applications not conforming to
NFPA regulations.
• Complies with EN54-12 for sensitivity levels between 25% and 35%, with a maximum delay to fire of 20
seconds.
Distance betweenTransmitter
and Receiver
Fire Threshold Range
5 - 10m (16.4 - 32.8 ft ) 25%
10 - 20m (32.8 - 65.6 ft ) 25 - 30%
20 - 40m (65.6 - 131.2 ft ) 25 - 45%
40 - 60m (131.2 - 196.8 ft ) 35 - 60%
60 - 80m (196.8 - 262.5 ft ) 45 - 60%
80 - 100m (262.5 - 328.1 ft ) 55 - 60%
100 - 120m (328.1 - 393.7 ft ) 60 %

Fireray 3000 Specifications

General

Detection Range	Up to 100m
Operating Temperature	-10°C to +55°C
IP Rating	IP65
Alarm Relay	1A @ 30V DC
Fault Relay	1A @ 30V DC
Detection Principle	Infrared beam
Response Time	10 seconds
Alarm Output	Relay
Current Consumption	≤25mA (standby), ≤45mA (alarm)
