14

The high water cutoff circuit has opened and caused the control to lock-
out (Terminal 23).
2
With oil selected, the low atomizing media switch has opened and caused
the control to lockout. (Terminal 30).
2
With gas selected, the low gas pressure switch has opened and caused
the control to lockout (Terminal 30).
2
The low oil pressure switch has opened and caused the control to lockout
(Terminal 28).
2
The low oil temperature switch has opened and caused the control to
lockout (Terminal 29).
2
The low water cutoff circuit has opened and caused the control to lockout
(Terminal 24).
2
The fuel selection switch was opened during or at the beginning of an
operation cycle. (Terminal 25 or 26).
2
The Flame-Monitor programmer has detected an error in attempting to
read the E300 Expansion Module.
LOCKOUT PURGE
2
3-P HIGH WATER
LOCKOUT PURGE
2
3-P LOW ATOMIZING MEDIA
LOCKOUT PURGE
2
3-P LOW GAS PRESSURE
LOCKOUT PURGE
2
3-P LOW OIL PRESSURE
LOCKOUT PURGE
2
3-P LOW OIL TEMPERATURE
LOCKOUT PURGE
2
3-P LOW WATER
LOCKOUT PURGE
2
3-P FUEL SELECTED
LOCKOUT PURGE
2
EXPANSION MODULE
