Fireye E300 - STANDBY MESSAGES; LOCKOUT MESSAGES

13
®
STANDBY MESSAGES DESCRIPTION
The auxiliary limit switch #1 in the operating control circuit has opened
and the control is waiting until the condition corrects itself.
2
The control
will hold this message indefinitely. (Terminal 21)
The auxiliary limit switch #2 in the operating control circuit has opened
and the control is waiting until the condition corrects itself. The control
will hold this message indefinitely. (Terminal 22)
The auxiliary limit switch #3 in the operating control circuit has opened
and the control is waiting until the condition corrects itself. The control
will hold this message indefinitely. (Terminal 13 on the FLAME-MON-
ITOR wiring base.)
LOCKOUT MESSAGES
1
DESCRIPTION
The air flow switch has opened and caused the control to lockout. (Ter-
minal P on the FLAME-MONITOR wiring base).
2
The auxiliary #4 limit switch has opened and caused the control to lock-
out. (Terminal 33).
2
The auxiliary #5 limit switch has opened and caused the control to lock-
out. (Terminal 34).
2
The auxiliary #6 limit switch has opened and caused the control to lock-
out. (Terminal 35.)
2
With gas selected, the high gas pressure switch has opened and caused
the control to lockout. (Terminal 27).
2
The high pressure switch has opened and caused the control to lockout.
(Terminal 31).
2
The high temperature switch has opened and caused the control to lock-
out (Terminal 32).
2
1.
Messages more than 16 characters in length will scroll from right to left on the bottom line of the display.
2.
The point in the operating sequence in which the lockout occurred will appear in the upper right hand corner of the display
(e.g. PURGE, PTFI, MTFI, or AUTO). On recycle-type programmers (e.g. EP260, EP270, or EP380, EP390 set for recycle
operation), the display will always indicate the LOCKOUT occurred during PURGE, even though the interlock could have
opened during Purge, PTFI, MTFI, or AUTO and failed to close within the first 10 minutes of purge following the recycle.
STANDBY
L1-13 AUX. #1 OPEN
STANDBY
L1-13 AUX. #2 OPEN
STANDBY
L1-13 AUX. #3 OPEN
LOCKOUT PURGE
2
3-P AIR FLOW OPEN
LOCKOUT PURGE
2
3-P AUX #4 OPEN
LOCKOUT PURGE
2
3-P AUX #5 OPEN
LOCKOUT PURGE
2
3-P AUX #6 OPEN
LOCKOUT PURGE
2
3-P HIGH GAS PRESSURE
LOCKOUT PURGE
2
3-P HIGH PRESSURE
LOCKOUT PURGE
2
3-P HIGH TEMPERATURE
