First Sales XTS30 - Component Parts Breakdown

15
Ref
Description
Model Number
XTS30
XTS45
XTS60
A
Control Valve w/
bypass
XTS30 Vlv Assy
W/BP
XTS45 Vlv Assy
W/BP
XTS60 Vlv Assy
W/BP
B
Mineral Tank
MTP0948GR
MTP1054GR
MTP1248GR
C
Distributor
D100S-48
D100S-54
D100S-48
D
Resin
Qty 2
H05P
Qty 3
H05P
Qty 4
H05P
E
1/4” X 1/8” Gravel
Qty 1
QC20
Qty 1
QC20
Qty 1
QC20
F
Brine Tank Assy.
BTSQ1833ASSY
BTSQ1833ASSY
BTSQ1833ASSY
G
Overflow Fitting
BT-OVERFLO
BT-OVERFLO
BT-OVERFLO
H
Safety Brine
Valve
SBV14ASSY
SBV14ASSY
SBV14ASSY
I
Salt Platform
BTSG18SQ
BTSG18SQ
BTSG18SQ
J
Bypass
BP 213
BP 213
BP 213
Component Parts Breakdown
