First Sales XTS30 - Installation Fitting Assemblies

17
1” PVC MALE NPT ELBOW
90 DEGREE BYPASS ELBOW
Ref
Part #
Description
Qty
Ref
Part #
Description
Qty
EBA900
1” Elbow Assembly
1*
EBA910
90° Bypass Elbow
Assembly
1*
1
EB100
1” Elbow
1
1
EB175
Bypass Elbow
1
2
OR324
O-ring, -324
1
2
OR324
O-ring, -324
1
3
C 101
Split Ring Retainer
1
3
C 101
Split Ring Retainer
1
4
C 102
Connector Nut
1
4
C 102
Connector Nut
1
1-1/2” PVC MALE NPT ELBOW
¾” PVC MALE NPT ELBOW
Ref
Part #
Description
Qty
Ref
Part #
Description
Qty
EBA915
1-1/2” Elbow Assembly
1*
EBA975
3/4” Elbow Assembly
1*
1
EB150
1.5” Elbow
1
1
EB750
3/4” Elbow
1
2
OR324
O-ring, -324
1
2
OR324
O-ring, -324
1
3
C 101
Split Ring Retainer
1
3
C 101
Split Ring Retainer
1
4
C 102
Connector Nut
1
4
C 102
Connector Nut
1
(*2 required)
Installation Fitting Assemblies
1
2
4
3
1
1
1
4
4
4
3
3
3
2
2
2
(*2 required)
(*2 required)
(*2 required)
