5
Press ‘SET’ button
to set time of day.
Press ‘↑’ button to advance to next step on CHECKLIST.
Press ‘↓’ button to repeat previous step.
When finished press ‘DONE’ to return to Home Screen.
“Step 3: Take extreme care to be sure the unit is NOT installed
backwards. Turn bypass valve to BYPASS position.
“Step 4: Connect drain line. Do NOT use vinyl tubing or ½” CPVC.
“Step 5: Avoid overhead drain line installations.
“Step 6: Drain line must NOT exceed 15’ in length.
“Step 7: Connect 3/8” tubing between control valve and salt tank.
“Step 8: Add 3 gallons of water to brine tank.
“Step 9: Add at least 40 pounds of water softener salt to brine tank.
“Step 10: DO NOT TAKE ANY ACTION UNTIL YOU HAVE LISTENED
TO THE REMAINING INSTRUCTIONS.
A. Advance control to BACKWASH
B. Crack open the inlet side of the bypass valve
C. Allow unit to slowly fill—pushing air out drain line
D. When a constant stream of water is discharged to drain,
advance control valve to RAPID RINSE and fully
open bypass valve. Allow system to complete this
step.
Pressing ‘DONE’ button
returns display to Home
Screen.
Prerecorded Basic Installation (cont.)
