Firstcom FR-488 - LCD Backlight; Pilot Frequency; Display Mode Setup; PIN Setup

25
8
General Setting
Tu rn selec tor knob t o s elect th e desir ed LCD back ligh t
3.
colors:Orange/Blue/Purple
Press
4.
to conrm and exit
Default:Orange
5.
LCD Backlight
Press and hold
1.
key for over 2s to
enter general setting menu.
Press
2.
/ key to choose No.25
menu, LCD displays"LAMP--25"
Turn selector knob to select the desired LCD backlight brightness
3.
1-32 total 32 level backlight brightness.
Press
4.
key to conrm and exit.Default:25.
Pilot Frequency
This function uses to start repeater .It needs a certain intensity Pilot
Frequency to start dormant repeater.As usual,no need to send pilot
frequency again once repeater started.
Press and hold
1.
key for over 2s to
enter general setting.
Press
2.
/ key to choose No.26
menu, LCD displays"TB--1750".
Turn selector knob to select the desired
3.
pilot frequency.
1750HZ:Pilot frequency1750HZ
2100HZ:Pilot frequency 2100HZ
1000HZ:Pilot frequency 1000HZ
1450HZ:Pilot frequency 1450HZ
Press
4.
key to conrm the selection and exit.Default:1750HZ
Display Mode Setup
There are 3 different dispaly modes: Frequency+Channel mode,&
Channel mode&Channel+Name Tag mode, .
Press and hold
1.
key for over 2s to enter general setting
menu.
Press
2.
/ key to choose No.27
menu, LCD displays"DSP—FR".
Turn selector knob to select the desired
3.
mode.
FR:Frequency+Channel mode(Amateur
transceiver mode).
C H : C h a n n e l m o d e ( P r o f e s s i o n a l
transceiver mode).
NM:Channel+Name Tag mode(Amateur transceiver mode),if
channel not named,it displays Frequency+Channel mode.
Press
4.
key to conrm and exit.Default:FR.
PIN Setup
Enable this function,you have to insert a matching PIN to enter
into normal status when radio is turned on.(Pin setup by programme
software).
This function will be auto-hidden if channel mode locked.(Refer to
programme software)
